Radiolink R8FG 2,4 Ghz 8 Ch mottaker Gyro Telemetri SBUS/PWM/PPM

R8FG 8CH Receiver Features:

• Excellent Anti-interference: With pseudo random FHSS algorithm, which makes R8FG with excellent anti-interference ability, control distance up to 1900 feet (600 meters). 1000 meter on water.

• Real-time Telemetry: telemetry feature can provide real-time vital information like vehicle's battery voltage, RSSI signal and more, avoiding the battery over-discharge and damage.

• Integrated Gyro: built-in gyro can keep the vehicle in a straight line, and Gyro sensitivity can be adjusted by transmitter, which fits for drifting and on-road cars.

• Push to Bind: No need bind plug and any setting, only press bind button for 1 second after power up controller and receiver. High resolution ratio of 4096, stable signal and fast response.

• Anti-polarity Protection: With reverse polarity protection, not damage the receiver even you insert wrong polarity. 4.6-10v DC support high voltage servo.

• Small Size with Compact Case: Only 30*18.5*11.5mm small size and 6g lightweight.

How to bind with transmitter:

1. Put the transmitter and the receiver close to each other within 50 cm.

2. Turn on the transmitter, then power on the R8FG.

3. There is a black button on the R8FG, press the binding button in one second until the receiver light starts blinking and release, after about 8 times blinking, match code success when receiver signal LED always on.

Attention: R8FG default have not turn on the gyro function. Make sure the R8FG keep motionless when power on it, because the R8FG will do the self-test. R8FG with two indicate LED, green LED on indicate normal working mode while both green and red LED on indicate gyro function working mode.

Package Included:

• R7FG Receiver x 1

• Voltage telemetry cable x1
